Structured packing TCIPAK 250Y
.jpg)
Metal Structured Packing(Metal Perforated Plate Corrugated Packing) is made of perforated plate with channel corrugation on surface,and remains structured feature of metal wire gauze packing.It strengthens uniform liquid distribution and surface wetting ability,which incerases mass transfer efficiency.
Structured packing TCIPAK 250Y
Metal perforated plate corrugated packing is available in a wide range of materials, include stainless steels, 304, 316, 316L, Carbonsteels. Aluminium, copper bronze etc. Further materials available on request.
Application Structured packing TCIPAK 250Y
Perforated plate corrugated packing with the wide range of applications.
Diameter: 0.1-12m; Pressure: Vacuum to high pressure;
Liquid lood: 0.2 to more than 300 m3/m2. H;
System: Ethylbenzene/ styrene, Fatty acide, cyclohex anone/ cyclohexanol, caprolaction, etc, Absorption desorption.
The technical specification: Structured packing TCIPAK 250Y
|
Type
|
specifific surface are m2/m3
|
Void Volume
%
|
Heaping Weight
Kg/m3
|
Wave
Height
mm
|
Theoretical plate
number
m-1
|
Δ P
Pa/m
|
Max.F-factor
m/s(kg/m3)0.5
|
|
125Y
|
125
|
98
|
85-100
|
25.4
|
1.0-2.0
|
150
|
3.0
|
|
250Y
|
250
|
97
|
170-200
|
12.5
|
2.0-3.0
|
200
|
2.6
|
|
350Y
|
350
|
94
|
240-280
|
9
|
2.0-2.5
|
300
|
2.0
|
|
500Y
|
500
|
92
|
360-400
|
6.3
|
4.0-5.0
|
180
|
1.8
|
|
